System window / door profiles

Window and door system sets extruded to your series, with gasket races and hardware channels formed in.

Start with the profile. Add the processing you need.

Order aluminum profiles and combine the operations your application requires in the same quotation.

Small-section extrusion

Small cross-section aluminum profiles for compact designs. Send the section drawing, alloy, wall thickness and required length for a feasibility review.

Small-batch color anodizing

Blue, red, yellow, green, purple and black color options for small-batch projects. Specify the quantity per color and provide a color sample or reference.

Processing to your drawing

Cutting, hole milling, drilling, welding and stretch bending can be quoted with your profiles. Include hole positions, bend geometry and assembly requirements.

Minimum section size, wall thickness, batch quantity and processing feasibility are confirmed from your drawing. Anodized shades depend on alloy, surface condition and sample approval; white finishes require confirmation of the finishing process.

For your quotation: section drawing · quantity by profile and color · cut lengths · machining or bending drawing · finish reference.

01Have these ready

Six things that turn a slow quote into a fast one.

Your system series, or reference profiles

The whole coordinated set is matched from it

Opening types — sliding, casement, tilt-turn

Each type pulls a different subset of profiles

Alloy, temper and wall spec

Strength, glazing weight and forming all trade here

Finish — anodized / powder / wood-grain

Books the right finishing line and colour

Gasket and hardware compatibility

Channels must accept the parts you already buy

Project quantity and delivery date

Drives price, scheduling and lead time

Window & door profiles / LB86 sliding window series

LB86 window profile catalogue

Browse by profile function or model code. Order profiles first and include cutting, machining or finishing requirements in your enquiry.

CAD illustrations from historical drawing references, not photographs. Similar-looking models are retained under their original codes; matching dimensions and interchangeability require drawing review. Final section, alloy, finish and supply conditions are confirmed per order.

Search model or profile nameProfile function

43 / 43 models shown

Frame, track & mullion profiles · 18

RUNNING ALUMINUM · LB8601

CAD illustration · LB8601

LB8601 · Sliding Window Head Track

Reference envelope: 83 × 40 mm

6063-T5 · CAD illustration

View CAD cross-section

RUNNING ALUMINUM · LB8601

CAD illustration · LB8601

Parameter	Working range
Alloy grades	6063 / 6060
Temper	T5 / T6
Profile length	up to 12,000 mm
Wall thickness	from 0.7 mm (0.3 mm on small sections →)
System set	Coordinated frames, sashes, gasket & hardware channels
Dimensional tolerance	to EN 12020 / ±0.1 mm
Surface finish	Anodized / Powder-coated / Wood-grain

System window / door profiles

Start with the profile. Add the processing you need.

Small-section extrusion

Small-batch color anodizing

Processing to your drawing

LB86 window profile catalogue

Frame, track & mullion profiles · 18

LB8601 · Sliding Window Head Track

LB8602 · Sliding Window Bottom Track

LB8603 · Sliding Window Jamb

LB8609 · Sliding Window Mullion

LB8610 · Intermediate Window Head Track

LB8611 · Intermediate Window Bottom Track

LB8612 · Fixed Window Frame

LB8616 · Window Track Profile

LB8617 · Sliding Window Bottom Track

LB8618 · Sliding Window Bottom Track

LB8619 · Double Window Jamb

LB8651 · Sliding Window Head Track

LB8652 · Sliding Window Bottom Track

LB8653 · Sliding Window Jamb

LB8659 · Window Mullion

LB8660 · Intermediate Window Head Track

LB8661 · Intermediate Window Bottom Track

LB8662 · Fixed Window Frame

Sash rails & stiles · 10

LB8604 · Sliding Sash Top Rail

LB8605 · Sliding Sash Inner Bottom Rail

LB8606 · Sliding Sash Outer Bottom Rail

LB8607 · Sliding Sash Interlock Stile

LB8608 · Sliding Sash Plain Stile

LB8654 · Sliding Sash Top Rail

LB8655 · Sliding Sash Inner Bottom Rail

LB8656 · Sliding Sash Outer Bottom Rail

LB8657 · Sliding Sash Interlock Stile

LB8658 · Sliding Sash Plain Stile

Single-glazed sash profiles · 5

LB8671 · Single-Glazed Sash Top Rail

LB8672 · Single-Glazed Sash Bottom Rail

LB8673 · Single Glazed Outer Bottom Rail

LB8674 · Sliding Sash Interlock Stile

LB8675 · Sliding Sash Plain Stile

Covers, couplings & corners · 5

LB8613 · Window Jamb Cover

LB8614 · Window Coupling Profile

LB8615 · 90 Degree Window Corner Profile

LB8663 · Window Corner Profile

LB8664 · Window Corner Profile

Triple-track profiles · 5

LB8680 · Triple-Track Window Head

LB8681 · Triple-Track Intermediate Bottom Rail

LB8682 · Triple-Track Fixed Frame

LB8683 · Triple-Track Window Jamb

LB8684 · Triple-Track Jamb Cover

Residential sets

Commercial glazing

Complete kits

Can we make it?

Machining & finish agreed

Proof before shipping
